Netis P124GH, 24 Port Fast Ethernet PoE Switch/802.3at/af,4*
NS-P124GH

**Netis P124GH 24-Port PoE Fast Ethernet Unmanaged Switch with 4 Gigabit and 4 SFP Ports**

The Netis P124GH is a versatile 30-port standard PoE switch, featuring 24 Fast Ethernet (FE) PoE ports, 4 Gigabit uplink ports, and 4 SFP fiber ports. Ports 1 to 24 support PoE power supply capabilities, allowing them to function with Power over Ethernet devices. This switch automatically detects and recognizes powered devices that comply with IEEE 802.3af/at standards, supplying power through the network cable. The 4 Gigabit uplink ports ensure smooth transmission for NVRs or uplink routers, making the P124GH an economical choice for HD security networks.

### Features

- Supports 802.3, 802.3u Fast Ethernet, and IEEE 802.3ab 1000BASE-T

- Compatible with PoE IEEE 802.3af/at compliant Powered Devices (PD)

- Modes: Normal switch mode and Extended mode (Port 1-24: 250 meters ultra-long transmission)

- 24 PoE-enabled ports for powering devices via Ethernet; 4x 10/100/1000Base-T uplink and 4x 1000Base-X SFP ports

- Full duplex support based on IEEE 802.3x and half duplex based on Backpressure

- Auto MDI/MDIX crossover for all ports

- Non-blocking wire speed forwarding

- MAC address auto-learning and aging

- Durable steel case with a total PoE power budget of 320W

- Simple plug-and-play setup

### Technical Specifications

- **Product**: Netis P124GH

- **Switch Type**: Unmanaged

- **Interfaces**:

  - 24x 10/100Mbps PoE ports (Data/Power)

  - 4x 10/100/1000M uplink RJ45 ports (Data)

  - 4x 10/100/1000M uplink SFP slot ports (Data)

- **MAC Address Table**: 16,000 entries

- **Switching Capacity**: 12.8 Gbit/s

- **Networking Standards**: IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
